How much floor space is needed for the installation of 4R Raymond milling equipment? Covering an area of the user is to buy machines need to consider one of the important factors, because the enterprise plant is not all big enough, if the high price to buy the mill, but because the site is too small can not be installed will bring a lot of trouble, 4R Raymond mill is one of the most commonly used models, production capacity is sufficient, the price is low, belongs to the medium-sized milling equipment, the footprint is not large, probably more than 50 square feet can be.

Raymond mill models are many, each type of mill host external dimensions are different, grinding production line installation footprint is in the mill model on the basis of a certain, plus other ancillary equipment together with the size of the footprint, need to emphasize one thing is that each model has a provision for the model of ancillary equipment, and the length of the pipeline, the height of the provisions are clear, do not recommend arbitrary modification, there are also customers before because the plant Smaller the overall change in the size of the evacuation pipe, resulting in powder suction, the return air pipe dust increased, low yield and other issues. 4R3216 Raymond machine dimensions of 7.1x5.9x7.9m, that is, the mill is 4.1m long, 5.9m wide, 7.9m high, covers an area of 4.1m long, 5.9m wide and 7.9m high, according to the length and width of the determination of the plant height based on the milling equipment to determine the highest point, where the 7.9m is only for the height of the mill main body! Here, 7.9 meters is only the height of the mill host, and the conveying pipeline needs to be installed on it, and the space for the maintenance device needs to be reserved, so the height of the plant needs to be a little higher.

Grinding equipment pipeline size change on the milling production line, the main role of the pipeline is the transportation and collection of powder, when the air volume is certain, it is reasonable to say that the greater the length of the pipeline output is lower, and vice versa, the higher, so the conveying pipeline will be based on the mill model and configuration of the size of the motor and calculate a better length of the conveying pipeline, there is a key point to emphasize, the size of the length of the cyclone collector device can not be changed, the collector is the only powder collector, and the length of the mill is the only one of the powder collector. Powder collector is the only powder collector, powder under the action of gravity materials and wind separation, if the collector pipe becomes shorter, the collection of powder is limited, when the finished product back to the wind pipe is closer there will be powder reflux, low yield and other issues, so at the beginning of the model selected mill installation size footprint is also a customized.

Raymond machine installation need to pay attention to what problems?

1. Before installation, the site should be designed by technicians to install the foundation, using reinforced concrete pouring.

2. Installation needs to be in the professional and technical know how to install correctly, pay attention to the installation order, installation steps, grinding rollers grinding ring and other precision parts to avoid bumping and other issues.

3. After the installation is completed, it should be checked one by one so as to see whether the installation is in place, whether there is any deviation and whether the bolts are tightened.

4. When all the preparations are completed, transmission parts lubrication and maintenance, completed after the line for a simple test run, in the normal into production.
