Jaw Crusher

Streamlined structure, Convenient maintenance

As the primary and secondary crushing equipment, jaw crusher is widely used in the crushing plant nowadays and has various advantages such as big crushing rate, equal end-product size, easy operation and maintenance. The highest anti-pressure of the end product can reach 320MPa.

Applications: Mining, metallurgy, construction, highway, railroad, and water conservancy, etc.

Jaw Crusher Advantages&Characteristics:
1.Strong main frame
2. High crushing ratio
3. Simple & quick discharge gap adjustment
4. High stability
5. High crushing capacity

Working Principle
The motor transmits power through belt, drives the moving jaw to do periodic motion towards the fixed jaw by the eccentric shaft. The angle between toggle plate and moving jaw plate increases when moving jaw moves . So the moving jaw moves towards the fixed jaw. The stuff will be crushed in this process. The angle between toggle plate and moving jaw decreases when moving jaw moves down, the moving jaw moves leaves fixed jaw by pulling rod and spring, the final crushed stuff will be discharged from the outlet.

Specifications - Technical Data
