Spring Cone Crusher Introduction

The spring cone crusher can perform medium, fine and coarse crushing of various materials with hardness not exceeding 350pa. It can be used as secondary, tertiary or quaternary crushing. It is an advanced crusher with high power, large crushing ratio and high productivity, which is widely used in various mining crushing production lines, sand crushing production lines. The following is the introduction of spring cone crusher and the principle of spring cone crusher.

Spring Cone Crusher Structure and Principle:

Spring cone crusher is mainly composed of frame, transmission, hollow eccentric shaft, bowl bearing, crushing cone, adjusting device, adjusting sleeve, spring and hydraulic station for adjusting discharge opening. When the crusher is in operation, the motor drives the eccentric sleeve through the horizontal shaft and a pair of bevel gears, and the axis of the crushing cone is forced by the eccentric sleeve to make a swinging motion, which makes the surface of the crushing wall close to and sometimes leave the surface of the molar wall, so that the ore is continuously crushed and bent in the crushing cavity, and the material is crushed to the required size and discharged from the lower discharge port.

Performance Introduction:

1. High flexibility, users can choose the crushing cavity type with high crushing efficiency, uniform product size and suitable grain size according to production needs.

2. Large crushing ratio, high production efficiency and high output.

3. The whole machine is of cast steel structure, with reinforcement bars in the heavy load part, and high strength of the whole machine.

4. It has a complete lubrication system, which will automatically shut down when there is too high temperature or too slow flow rate.

5. The internal structure has good sealing performance, which can effectively protect the equipment from dust and other small particles.

6. Using dry oil or water two kinds of sealing methods, so that dust and impurities can not enter the body, so as to ensure the cleanliness of the lubricant oil, prolong the service life of the slide bearing, thrust ball bearing, reduce production costs.

The above is the introduction of spring cone crusher, if you are interested in further understanding the spring cone crusher, you can contact our customer service staff, 24 hours free online consultation.
