Raymond mill application and preparation before installation

Raymond mill is an industrial grinding equipment, which is mainly used for powdering ore materials. The equipment belongs to the disc immovable disk mill, is a practical and better powder making products. With a wide range of powder making, uniform particle size and adjustable, reasonable structure, small footprint and other advantages.

Coammon materials that can be powdered by Raymond Mill:

1. Soil: clay, china clay, bentonite, kaolin, potter's clay, bauxite and so on.

2. Non-metallic minerals: gypsum, talc, calcite, limestone, graphite, barite, feldspar, shale and so on.

3. Metal oxides: ferromanganese, chromite, ilmenite, titanium oxide, bauxite and so on.

Characteristics of the above processed materials: Raymond mill is mainly used for grinding various non-flammable and explosive mineral materials with Moh's hardness below grade 7 and humidity below 6%.

Raymond Mill Usage:

Raymond mill has a very wide range of uses, after Raymond mill grinding made of products can be used in many industries. Such as metallurgical industry with magnesium powder for blast furnace refractory layer; petroleum development using barite powder pressure sealing injection port; bentonite powder slurry as a lubricant for drilling; chemical and light industry with different stone powder for rubber, plastics, papermaking, coatings in the filler; building materials industry, ceramics, glass, enamel, white cement, gypsum products.

When you have selected the Raymond mill, next you have to prepare for the installation.

1. When the Raymond mill is transported to the site, it can not be installed and used for a while, it should be properly stored to avoid rusting of the machine parts after exposure to sun and rain. Gold processing exposed surfaces, shall be coated with rust-resistant grease, to establish a "Raymond Mill maintenance system.

2. According to the specific conditions of the site combined with the foundation plan, with high grade cement configuration of reinforcing steel poured foundation, and pre-buried threading stay or make a good cable trench.

3. The cement foundation must have enough time for curing period.

4. The configuration of the plant should be based on the size of the Raymond mill drawing, leaving enough height and location.

5. Raymond mill installation site should be equipped with the following lifting tools for installation and maintenance: 3R should have a lifting capacity of 2t lifting tools; 4R - 2-3t lifting tools; 5R - 5t lifting tools; 6R - 10t lifting tools.

6. The main components of Raymond mill, such as the transmission device, grinding roller device, the center shaft part and the analyzer oil pool part, from the factory to the use of time more than six months, it is generally appropriate to clean and check.

7. After cleaning and checking, each transmission part should add enough grease.
